Dimensions & Tolerances for ASTM B111 Copper & Copper-Alloy Tubes

ASTM B111 is the standard specification for copper and copper-alloy seamless condenser tubes and ferrule stock. When dimensional inspection is finally conducted, outside diameter, wall thickness and length of the tubing shall be examined in accordance with Section 14 of the standard. The dimensions & permissible variations (tolerances) prescribed in Section 14 are applicable to ASTM B111 seamless condenser tubes made from a series of copper and copper alloy in UNS designations of C10100, C10200, C10300, C10800, C12000, C12200, C14200, C19200, C23000, C28000, C44300, C44400, C44500, C60800, C61300, C61400, C68700, C70400, C70600, C70620, C71000, C71500, 71520, C71640, C72200. All the dimensions may be stated in either SI units or inch-pound units, and each system shall be used independently of each other.

Outside Diameters & Permissible Variations

The outside diameter of a ASTM B111 seamless condenser tubing shall be no greater than 3.125″ [80 mm]. Since a tubing is determined by its outside diameter and wall thickness (usually in Birmingham Wire Gauge – BWG number), the permissible variations (tolerances) of the outside diameter may vary with the combination of outside diameter and wall thickness.

Outside Diameter	Wall Thickness
	0.020 0.022 0.025 0.028	0.032	0.035
d≤0.500	±0.003	±0.0025	±0.0025
0.500＜d≤0.740	±0.004	±0.004	±0.004
0.740＜d≤1.000	±0.006	±0.006	±0.005
1.000＜d≤1.250	-	±0.009	±0.008

*All values are in inch units, for tubes with wall thickness from 0.020″ to 0.035″.

Outside Diameter	Wall Thickness
	0.042	≥0.049
d≤0.500	±0.0025	±0.0025
0.500＜d≤0.740	±0.0035	±0.003
0.740＜d≤1.000	±0.0045	±0.004
1.000＜d≤1.250	±0.006	±0.0045
1.250＜d≤1.375	±0.008	±0.005
1.375＜d≤2.000	-	±0.006
2.000＜d≤3.125	-	±0.0065

*All values are in inch units, for tubes with wall thickness no less than 0.042″.

Outside Diameter	Wall Thickness
	0.508 0.559 0.635 0.711	0.813	0.889
d≤12	±0.076	±0.064	±0.064
12＜d≤18	±0.10	±0.10	±0.10
18＜d≤25	±0.15	±0.15	±0.13

*All values are in SI units, for tubes with wall thickness from 0.508 mm to 0.889 mm.

Outside Diameter	Wall Thickness
	1.07	≥1.24
d≤12	±0.064	±0.064
12＜d≤18	±0.089	±0.076
18＜d≤25	±0.11	±0.10
25＜d≤35	±0.20	±0.13
35＜d≤50	-	±0.15
50＜d≤80	-	±0.17

*All values are in SI units, for tubes with wall thickness no less than 1.07mm.

Wall Thicknesses & Tolerances

The wall thickness of the ASTM B111 seamless condenser tubing usually is furnished between 0.020″ to 0.134″ (0.51 mm to 3.40 mm).

Wall Thickness inch	For Outside Diameter, inch
	0.125＜d≤0.625	0.625＜d≤1.000
0.020≤t＜0.030	±0.003	±0.003
0.032≤t＜0.035	±0.003	±0.003
0.035≤t＜0.058	±0.004	±0.0045
0.058≤t＜0.083	±0.0045	±0.005
0.083≤t＜0.120	±0.005	±0.0065
0.120≤t＜0.134	±0.007	±0.007

*All values are in inch units, for tubing with outside diameter from 1/8″ to 1″.

Wall Thickness inch	For Outside Diameter, inch
	1.00＜d≤2.00	2.00＜d≤3.125
0.020≤t＜0.030	-	-
0.032≤t＜0.035	±0.004	-
0.035≤t＜0.058	±0.0045	±0.005
0.058≤t＜0.083	±0.005	±0.0055
0.083≤t＜0.120	±0.0065	±0.0065
0.120≤t＜0.134	±0.0075	±0.008

*All values are in inch units, for tubing with outside diameter from 1″ to 3.125″.

Wall Thickness mm	For Outside Diameter, mm
	12＜d≤25	25＜d≤50	50＜d≤80
0.50≤t＜0.80	±0.08	-	-
0.80≤t＜0.90	±0.08	±0.10	-
0.90≤t＜1.50	±0.11	±0.11	±0.13
1.50≤t＜2.10	±0.13	±0.13	±0.14
2.10≤t＜3.00	±0.17	±0.17	±0.17
3.00≤t＜3.40	±0.18	±0.19	±0.20

*All values are in SI units, for tubing with outside diameter from 12 mm to 80 mm.

Lengths & Tolerances

The length of ASTM B111 seamless condenser tubes shall not be over 100 feet. Tolerances for lengths in wall thicknesses of 0.020″ to 0032″ shall be agreed upon between the supplier and the buyer.

Length feet	Tolerances inch
l≤15'	(0,＋3/32“)
15'＜l≤20'	(0,＋1/8“)
20'＜l≤30'	(0,＋5/32“)
30'＜l≤60'	(0,＋3/8“)
60'＜l≤100'	(0,＋1/2“)

*Tolerances for lengths in inch units.

Length mm	Tolerances mm
l≤4500	(0, +2.4)
4500＜l≤6000	(0, ＋3.2)
6000＜l≤10000	(0, ＋4.0)
10000＜l≤18000	(0, ＋9.5)
18000＜l≤30000	(0, +13.0)

*Tolerances for lengths in SI units.
